6Rolls/Bundle 280Meters Length Welded mesh For concrete weight-coated pipeline

Brand Name : H&F

Model Number : HF-250904

Certification : ISO-9001

Place of Origin : Hebei, China

MOQ : 22700 Square Meters

Price : USD2.94/M2~USD3.58/M2

Payment Terms : T/T,Western Union

Supply Ability : 65000 Square Meters per month

Delivery Time : According to order quantity

Packaging Details : 6 rolls per bundle or as customers' requirements

Product Name : 6Rolls/Bundle 280Meters Length Welded mesh

Key word : Pipe reinforced welded mesh

Wire diameter : 1.6mm-2.8mm

Line wire quantity : 6lines or 8lines,10Lines

Exposed Wire Edge : ≤ 2.5 mm

Material : Hot dipped Galvanized wire

Middle line wire pitch : 25.4 mm

Zinc coated : 70gm²~300g / m² or custom

Surface treatment : hot dipped galvanized

Hole Size : 25.4mm x 67mm

Cross wire pitch : 67 mm or 92.4 mm

Hardness range : 485N/mm2~650N/mm2

Both sides line wire pitch : 25.4 mm or 50.8 mm

Width : 190.5mm

Length : 140m,145m,150m,280m etc

Load container way : In bulk or in pallet

Roll Diameter : 700mm~1100mm

Sample : Supply free sample can test quality

Contact Now

6Rolls/Bundle 280Meters Length Welded mesh For concrete weight-coated pipeline

Product Specifications

Attribute	Value
Product Name	Welded mesh For concrete weight-coated pipeline
Key word	Pipe reinforced welded mesh
Material	Hot dipped Galvanized wire
Surface treatment	Hot dipped galvanized
Hole Size	25.4mm x 67mm
Line wire quantity	6lines or 8lines, 10Lines
Wire diameter	1.6mm-2.8mm
Middle line wire pitch	25.4 mm
Exposed Wire Edge	≤ 2.5 mm
Zinc coated	70gm²~300g / m² or custom
Cross wire pitch	67 mm or 92.4 mm
Hardness range	485N/mm²~650N/mm²
Both sides line wire pitch	25.4 mm or 50.8 mm
Width	190.5mm
Length	140m, 145m, 280m etc
Roll Diameter	700mm~1100mm
Load container way	In bulk or in pallet
Sample	Supply free sample to test

Product Description

Steel Pipe Winding mesh is we specially designed and make for Water and Wastewater Pipeline/offshore oil and gas pipeline applications. Manufactured from Export high-grade quality hot dipped galvanized wire, its features strong,anti-rust,high tensile and uniform hole sizes with excellent durability.Make sure long time use and save cost.

Technical Specifications

Product Name	Welded mesh For concrete weight-coated pipeline
Material	Hot dipped galvanized wire
Wire diameter	1.6mm-2.8mm
Hole size	25.4mm x 67mm
Surface treatment	Hot dipped galvanized
Zinc coated	70gm²~300g / m² or custom
Middle line wire pitch	25.4 mm
Cross wire pitch	67 mm or 92.4 mm
Both sides line wire pitch	25.4 mm or 50.8 mm
Line wire quantity	6lines, 8lines or 10lines
Exposed Wire Edge	≤ 2.5 mm
Hardness range	485N/mm²~650N/mm²
Roll Diameter	700mm-1150mm
Width dimensions	190.5mm
Length dimensions	140m, 145m, 280m etc
Sample	Supply free sample to test

Product Variants

6Rolls/Bundle 280Meters Length Welded mesh For concrete weight-coated pipeline

Key Advantages

High grade Export quality
New material wire
Standard wire diameter
Lowest tolerance
Standard roll width
Enough Roll length and custom length
Precision hole sizing
Uniform hole size design
Anti-rust
Anti-corrosion
Strong welded point
Tensile strength high
Service life long
Easy to use and store
Secure packaging options

Packaging Options

1-6 rolls per bundle
Sturdy pallet packaging
Reinforced wooden boxes
Bulk container loading
Custom packaging available

Applications

River Bottom Gas & Oil Pipeline
Everglades Gas Pipeline
Chemical Processing Pipeline
Subsea Gas & Oil Pipeline
Water and Wastewater Pipeline
